Product Description
Product introduction
The CRI2000 Rubber injection molding machine is divided into a FILO injection device and a FIFO injection device.
Heating plate size: 550 mm×550 mm.
Clamping force: 2000 KN.
Applications
Compact and efficient, CHAP rubber injection molding machine is particularly suitable for producing rubber products that are difficult to mold, like those with complex shapes.
Features
The CRI2000 rubber injection molding machine features two operation modes: manual and semi-automatic
This rubber injection machine is equipped with a fully enclosed security screen and an infrared light curtain protection device, thus giving the machine a higher level of safety during operation.
This machine's preformed plastic injection barrel is heated with hot oil, which can better control machine's temperature.
This molding machine features a four-cylinder parallel injection structure which improves the balance during the rubber injection process, and cuts down on the longitudinal space of the injection component. As a result, the injection plunger is easy to remove.
This machine is very compact in structure, which significantly improves its adaptability to different applications.
Technical Specifications of Rubber Injection Molding Machine
| CRI2000 | CRI2000 | |
| Clamping force | 2000 KN | 2000 KN |
| Heating plate size | 550 mm×550 mm | 550 mm×550 mm |
| Heating plate spacing | 450~550 mm | 450~550 mm |
| Theoretical injection capacity | 2000cm3 | 2000cc |
| Screw diameter | ￠50 mm | ￠45 mm |
| Screw rotational speed | 0~120 r/min | 0~120 r/min |
| Plunger diameter | ￠70 mm | ￠90 mm |
| Injection pressure | 170 Mpa | 170 Mpa |
| Mould opening stroke | 400 mm | 400 mm |
| Motor power | 15KW | 15KW |
| Heating power | 16.4KW | 16.4KW |
| External dimension (LxWxH) | 3200mm×2050mm×4100mm | 3320mm×1850mm×4100mm |
| Oil tank capacity | 380L | 380L |
As a professional vacuum rubber vulcanizing machine manufacturer in China, CHAP is ISO9001 certified due to its production and operation in rigid compliance with international standards. With superior quality, reliable performance, and high efficiency, our products, such as plate rubber vulcanizing machine, rubber transfer molding machine, custom rubber machine, and more, are well received by global customers in South America, Southeast Asia, East Asia, and Middle East, etc.Here we have convenient access to any kind of transportation, which not only can save our transportation cost of raw materials, but also can lower your purchasing cost. If you have any needs about our products, please contact us via email or contact address available on this website.We are ready to serve you.
